Audison AF C4D Amplifier | 600 W total power | 4 x 150 W @ 2ohm | D-class Fully Bridgeable
Audison AF C4D Amplifier | 600 W total power | 4 x 150 W @ 2ohm | D-class Fully Bridgeable
FEATURES
- Improved audio performance and power thanks to the latest generation of ADT (Audison D-Class) technology
- Unbeatable power/volume ratio up to 0.47 W RMS/cm³ reaching 81% of efficiency
- Hi-Res compatibility performance, with an extended audio band up to 40 kHz
- Maximum versatility thanks to the possibility of using the bridging option for each pair of power outputs
AMPLIFIER TECH DATA
Channels 4
Class D-Class
Efficiency 84%
Hi Level Input Yes
Low Level Input Yes
Digital Input No
Power supply voltage / fuse 11 ÷ 15 VDC
Operating power supply voltage 6.5 ÷ 17.5 VDC
Idling current 0.004 A
Idling current when off 0.6 mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power 25 A
Remote OUT 6.5 ÷15 VDC (150 mA)
Remote IN 4 ÷15 VDC (1 mA)
ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable) 1.5 VDC
AMPLIFIER STAGE
Distortion - THD @ 100 Hz, 4Ω, 70% Rated Power 0,03%
Bandwidth A (-3 dB, 2 VRMS, 4 Ω): 10Hz ÷ 40kHz
S/N ratio A (A weighted @ 1 V): 102 dBA
Damping factor A (1 kHz, 4Ω, 2 VRMS): 95
Input sensitivity Pre-In 0.6 ÷ 6 VRMS
Input sensitivity Speaker-In 2.2 ÷ 22 VRMS
Total Power RMS 600 W
Minimum load impedance 2Ω:
Output Power (RMS) @14.4 VDC, 1% THD 4Ch @ 4Ω: 90 W x 4
4Ch @ 2Ω: 150 W x 4
2Ch (bridge) @ 4Ω: 300 W x 2
Adjustable Crossover No
