Audison AV due Amplifier | 900 W total power | 2 x 450 W @ 2ohm | AB-class

• Hi-Res audio certification thanks to 4 ÷ 60k Hz bandwidth
• 2 x 450 W @ 2-ohm audiophile AB Class
• Built-in 24 dB/oct filters

AMPLIFIER TECH DATA
Channels    2
Class    AB-Class
Hi Level Input    Yes
Low Level Input    Yes
Digital Input    Yes
Power supply voltage / fuse    11 ÷ 15 VDC
Idling current    1.7 A
Idling current when off    0.02 mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power    65 A
Remote OUT    12 VDC - 50mA
Remote IN    7 ÷ 15 VDC - 1mA
ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable)    Selectable

AMPLIFIER STAGE
Distortion - THD @ 100 Hz, 4Ω, 70% Rated Power    0.04 %
Bandwidth A    (-3 dB, 2 VRMS, 4 Ω): 4 ÷ 60k Hz
S/N ratio A    (A weighted @ 1 V): 100 dBA
Damping factor A    (1kHz, 4 Ohms): 120
Input sensitivity Pre-In    0.3 ÷ 5 V RMS
Pre In Impedance    15k Ω
Input sensitivity Speaker-In    1.4 ÷ 24 V RMS
Input impedance Speaker-In    5k Ω
Total Power RMS    900 W
Minimum load impedance    2Ω
Output Power (RMS) @14.4 VDC, 1% THD    • 2 Ch: 260 W x 2 (4Ω)

• 2 Ch: 450 W x 2 (2Ω)

• 1 Ch: 900 W x 1 (4Ω)
Adjustable Crossover    Yes
