JL Home 600W Amplifier/Processor w/Rack Mount Option & JLink Connectivity

Product highlights:

•  Pristine, stereo audio circuit pathways used throughout
• Intuitive interface with LCD display provides detailed control of on-board settings and functions
• On-board, 2-way active crossover (12/24 dB per octave), capable of supporting a stereo system with a low-pass filtered subwoofer output and high-pass filtered line outputs to feed the main speakers’ amplifier
• Built-in, optimized equalizer curves for use with JL Audio subwoofers systems
• Fixed or variable level control options

• Selectable polarity control (0 or 180 degrees) to optimize subwoofer integration

• Programmable delay controls for the SA-600W’s subwoofer outputs and line outputs.

• E.L.F. (Extreme Low Frequency) trim applies equalizer cut or boost at 25 Hz (-12 to + 3 dB) to tailor a subwoofer’s response for a particular room.

• D.A.R.O. (Digital Automatic Room Optimization) automatically measures and corrects in-room response to optimize low frequency performance (requires optional JL Audio calibration microphone – CAL-MIC1 – sold separately)

• Three band parametric equalizer with configurable center frequency, Q and gain, to further optimize subwoofer system response

• Grounded or Isolated input mode options for quiet, noise-free performance

• Stereo, high-level inputs accept direct connection from amplified receiver outputs when no line level signal is available.

• Wireless signal connectivity is available via the optional JLink™ Transmitter/Receiver system (JLink™ TRX – sold separately).

• Automatic turn-on options via signal sensing or 12V trigger. 12V input and output triggers to control additional SA-600Ws or peripheral equipment

• Front-mounted USB port and DFU button provides easy access to update firmware.

• Versatile mounting options for table-top setups or rack-mount installations.
