Audison AF M8.14 bit DSP Amplifier | 1120 W | 14 CH DSP + 8 x 140 W @ 2 ohm | D-class Fully Bridgeable
Audison AF M8.14 bit DSP Amplifier | 1120 W | 14 CH DSP + 8 x 140 W @ 2 ohm | D-class Fully Bridgeable
Regular price
$1,700.00
Regular price
Sale price
$1,700.00
Unit price
per
FEATURES
- Improved audio performance and power thanks to the latest generation of ADT (Audison D-Class) technology
- Unbeatable power/volume ratio up to 0.68 W RMS/cm³ reaching 82% of efficiency
- Next-generation bit Drive software platform
- Hi-Res compatibility performance, with an extended audio band up to 40 kHz, made possible by and DSP working operation at 24 bit/96 kHz
- Maximum versatility thanks to the possibility of using the bridging option for each pair of power outputs
- Up to 14 output channels (8 amplified, 6 optional pre-outs) controlled by the DSP to expand the system with other amplifiers
- 8 high/low-level inputs (and an optical Toslink digital input) support total connectivity even with the most complex OEM systems
- Extension card slot (additional 4 analogs or 1 digital input)
- Electrical signal analysis for each input channel ensures proper integration and correction
- Acoustic analysis (with your USB microphone) integrates the response graph into the equalizer display. This ensures efficient tuning and great sound!
- Advanced signal routing options allow the technician to go beyond the predefined system definitions in the Configuration Wizard
AMPLIFIER TECH DATA
Channels 8
Class D-Class
Power supply voltage / fuse 11 ÷ 15 VDC / 2 x 30A
Operating power supply voltage 6.5 ÷ 17.5 VDC
Idling current 1.5 A
Standby Current Draw 1.7 mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power 55 A
Remote IN 4 ÷15 VDC (1 mA)
Remote OUT 6.5 ÷15 VDC (150 mA)
ART - Automatic Remote Turn on/ off from OUTPUT BTL speakers 1.5 VDC
Efficiency Rated Power 82%
